Additional Features
 | No-Skew Printing |
 | Tension Weight Take-Up |
 | Roland DG Bulk Ink-Switching System |
 | Super Sharp Images with Long-Lasting Color |
 | Multi-Function SBL3 Ink |
 | Optimized Print Heads |
 | Fine Media Options |
 | Fluorescent Inks Available |
Texart™ RT-640M Specification
| Model | RT-640M | |
| Printing Technology | Piezoelectric inkjet | |
| Media | ||
| Width | 259 to 1625 mm (10.2 to 64 in.) | |
| Thickness | Max. 1 mm (39 mil) | |
| Roll outer diameter | Max. 210 mm (8.3 in.) | |
| Roll weight | Max. 40 kg (88 lb) | |
| Core diameter*1 | 76.2 mm (3 in.) or 50.8 mm (2 in.) | |
| Printing width*2 | Max. 1615 mm (63.6 in.) | |
| Ink | Type | Texart ink, 1000 cc pouch |
| Colors | 4 colors (Cyan, Magenta, Yellow, Black) 8 colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Orange, Violet) 8 colors Fluorescent (Cyan, Magenta, Yellow, Black, Orange, Violet, Fluorescent Yellow, Fluorescent Pink) | |
| Print resolution (dots per inch) | Max. 1440 dpi | |
| Distance accuracy*3 | Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater | |
| Connectivity | Ethernet (10BASE-T/100BASE-TX, automatic switching) | |
| Power-saving function | Automatic sleep feature | |
| Power requirements | AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz | |
| Power consumption | During operation | Approx. 140 W |
| Sleep mode | Approx. 31 W | |
| Acoustic noise level | During operation | 62 dB (A) or less |
| During standby | 49 dB (A) or less | |
| Dimensions (with stand) | 2650 (W) x 795 (D) x 1600 (H) mm (104.4 x 31.3 x 63 in.) | |
| Weight (with stand) | 160 kg (353 lb) | |
| Environment | Power on | Temperature: 18 to 25°C (64.4 to 77°F), humidity: 35 to 65% RH (no condensation) |
| Power off | Temperature: 15 to 30°C (59 to 86°F), humidity: 20 to 80% RH (no condensation) | |
| Included items | RIP software, take-up system, exclusive stands, power cable, media clamps, media holder, User’s Manual, etc. | |
| Software | ErgoSoft Roland Edition 2 | |
*1 The media holder for this machine is exclusively designed for media rolls with a paper tube measuring 76.2 mm (3 in.) in diameter. To use 50.8 mm (2in.) media rolls, the optional media flanges are required.
*2 The length of the production run is subject to the limitations of the program.
*3 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Excluding expansion / contraction of the media. All corrections or adjustment functions of this machine have been made properly. Print travel: 1 m.
Specifications, designs and dimensions listed may be subject to change without notice.
| ErgoSoft Roland Edition 2 System Requirements | ||
| Operating system | Windows® 10 (32/64-bit) Windows® 8/8.1 (32/64-bit) Windows® 7 Professional (32/64-bit) Windows® 7 Home (32/64-bit) | |
| CPU | Intel® Core™ i3; 3 GHz or faster recommended | |
| RAM | 8GB or more recommended | |
| Video card and monitor | Screen resolution of 1600 x 900 or higher recommended | |
| Free disk space (HDD/SSD) | 100 GB or more recommended | |
INKJET INK | |
| Part No. | Description |
| SBL3-BK | Texart Sublimation Ink 1L Pouch, Black |
| SBL3-CY | Texart Sublimation Ink 1L Pouch, Cyan |
| SBL3-FP | Texart Sublimation Ink 1L Pouch, Fluor Pink |
| SBL3-FY | Texart Sublimation Ink 1L Pouch, Fluor Yellow |
| SBL3-LC | Texart Sublimation Ink 1L Pouch, Light Cyan |
| SBL3-LM | Texart Sublimation Ink 1L Pouch, Light Magenta |
| SBL3-MG | Texart Sublimation Ink 1L Pouch, Magenta |
| SBL3-OR | Texart Sublimation Ink 1L Pouch, Orange |
| SBL3-VI | Texart Sublimation Ink 1L Pouch, Violet |
| SBL3-YE | Texart Sublimation Ink 1L Pouch, Yellow |
| CONSUMABLES | |
| Part No. | Description |
| IJ-SWABKIT5-50 | Swab Kit, 5 inch Swabs, 50 Pack |
| US-CLNFLD-500 | Cleaning Fluid, Water-based, 500cc bottle |
| US-IJ-CL | Cleaning Cartridge for RT-640, XT-640 |
| OTHER | |
| Part No. | Description |
| H150.2100 | ErgoSoft Roland Edition 2 – dongle packet |
| H151.2000 | ErgoSoft Roland Edition 2 PLUS |
| H152.2000 | ErgoSoft Roland Edition 2 – ColorGPS Profiler |
| H152.2100 | ErgoSoft Roland Edition 2 – TrueShape Nesting |
| ROLAND MEDIA | |
| Part No. | Description |
| DSM-RTP-443-64 | Texart Sublimation Paper, 95 gsm, 64in x 443ft |
