Discover More Applications with DE-3 Engraving
Effortlessly scribe and engrave onto a huge range of giftware, signage, trophies, tools and industrial products. Personalize brass, aluminum, copper, plastic engraving blanks, wooden items and more, with the speed, precision and ease of the powerfully compact DE-3.
Specifications
DE-3
| Work table size | 305mm x 230mm 12.0079in x 9.05512in | |
| Maximum Work Area (Work Envelope) | 12” (X) x 9.1” (Y) x 1.6” (Z) 305 mm (X) x 230 mm (Y) x 40mm (Z) | |
| XYZ Axis Drive System | Stepper motor, 3-axis simultaneous control | |
| Operating Speed | XY axis: | 0.1 ～ 60 mm/sec. |
| Z axis: | 0.1 ～ 30mm/sec. | |
| Software Resolution | 0.004” (0.01 mm) /step | |
| Mechanical Resolution | XYZ-axis: | 0.00125 mm/step |
| Spindle Motor | Brushless DC Motor | |
| Spindle Speed | 5,000 ～ 20,000 rpm | |
| Tool Loading | Cutter Holder, Collet Type | |
| Maximum Material Thickness | 40 mm（38 mm when using the nose cone） | |
| Connection | USB | |
| Ethernet（10 BASE-T/100 BASE-TX） | ||
| Machine Language | RML-1 | |
| Power Supply | Voltage and Frequency | AC 100V – 240V ± 10%、50/60Hz（Overvoltage category: Category Ⅱ, IEC60664-1) |
| Rated Current | 1.0 A | |
| Power Consumption | 80 W | |
| Operating Noise | While Operating： | 60 dB（or less) |
| Standby： | 40 dB（or less) | |
| External Dimensions | 2’02” (W) x 1’9″ (D) x 1’2″ (H) (616 mm (W) × 587 mm (D) × 390mm (H)) | |
| Machine Weight | 75 lbs (35 kg) | |
| Installation Environment | Indoor use, altitude: | 2000 m or less |
| Temperature | 5 to 40 °C | |
| Humidity | 35 to 80% (no dew condensation) | |
| Environment pollution degree: | 2 | |
| Bundled Accessories | “Power cord, power adapter, USB cable, nose cone unit (resin / metal components), nose unit set screw (fixing screw, spring), spare set screw (for cutter holder) , Solid collet (∅ 3.175 mm), spanner wrench, hex wrench, hex driver, adhesive sheet, dust collector adapter, DGSHAPE Software Package CD, Setup Guide” | |
